Model Evaluation¶
Goals¶
- Minimize bias
- Minimize variance
- Minimize generalization gap
Guidelines¶
- Metrics computed from validation set may not be representative of the true population
- Never trust a single summary metric
- Always look at all the individual metrics
- false positives and false negatives are seldom equivalent
- understand the problem to known the right tradeoff
Model Selection¶
- Fit multiple models \(g_i\) on the training data
- Use interval validation data for hyper parameter tuning of each model \(g_i\)
- Use external validation data for model selection and obtain \(g^*\)
- Combine the training and validation data. Refit \(g^*\) on this set to obtain \(g^{**}\)
- Assess the performance of \(g^{**}\) on the test data
Finally, train \(g^{**}\) on the entire data to obtain \(\hat f\)
Baseline¶
Always establish a baseline
- Basic/Naive/Dummy predictions
-
Regression
- Mean
- Max
- Min
-
Classification
- Most frequent value
- Random
-
Time series specific
- Lag/Seasonal Lag
- Last value available
-
Human Level Performance
- Literature Review
- Performance of older system
Significance¶
All the evaluation should be performed relative to the baseline.
For eg: Relative RMSE = RMSE(model)/RMSE(baseline), with “good” threshold as 1
Probabilistic Evaluation¶
Now, we need to see if any increase or decrease in accuracy due to hyper-parameter tuning is statistically-significant, or just a matter of chance.
Regression Evaluation¶
Metric | Formula | Unit | Range | Preferred Value | Signifies | Advantages ✅ | Disadvantages ❌ | Comment |
---|---|---|---|---|---|---|---|---|
\(R^2\) (Coefficient of Determination) | \(1 - \text{RSE}\) | Unitless | \([0, 1]\) | \(1\) | Proportion of changes in dependent var explained by regressors. Proportion of variance in \(y\) explained by model wrt variance explained by mean Demonstrates ___ of regressors - Relevance - Power - Importance | Cannot use to compare same model on different samples, as it depends on variance of sample Susceptible to spurious regression, as it increases automatically when increasing predictors | ||
Adjusted \(R^2\) | \(1 - \left[\dfrac{(1-R^2)(n-1)}{(n-k-1)}\right]\) | Unitless | \([0, 1]\) | \(1\) | Penalizes large number of predictors | |||
Accuracy | \(100 - \text{MAPE}\) | % | \([0, 100]\) | \(100 \%\) | ||||
Chi-Squared \(\chi^2\) | \(\sum \left( \dfrac{u_i}{\sigma_i^2} \right)^2\) | \(0\) | ||||||
Spearman’s Correlation | \(\dfrac{ \text{Cov}(\ rg( \hat y), rg(y) \ ) }{ \sigma(\ rg(\hat y) \ ) \cdot \sigma( \ rg(y) \ ) }\) | Unitless | \([-1, 1]\) | \(1\) | Very robust against outliers Invariant under monotone transformations of \(y\) | |||
DW (Durbin-Watson Stat) | \(> 2\) | Confidence of error term being random process | Not appropriate when \(k>n\) | Similar to \(t\) or \(z\) value If \(R^2 >\) DW Statistic, there is Spurious Regression | ||||
AIC Akaike Information Criterion | \(-2 \ln L + 2k\) | \(0\) | Leave-one-out cross validation score | Penalizes predictors more heavily than \(R_\text{adj}^2\) | For small values of \(n\), selects too many predictors Not appropriate when \(k>n\) | |||
AIC Corrected | \(\text{AIC} + \dfrac{2k(k+1)}{n-k-1}\) | \(0\) | Encourages feature selection | |||||
BIC/SBIC/SC (Schwarz’s Bayesian Information Criterion) | \(-2 \ln L + k \ln n\) | \(0\) | Penalizes predictors more heavily than AIC | |||||
HQIC Hannan-Quinn Information Criterion | \(-2 \ln L + 2k \ln \vert \ln n \vert\) | \(0\) |
\(\chi^2_\text{reduced} = \dfrac{\chi^2}{n-k}\) | Meaning |
---|---|
\(\approx 1\) | Good Fit |
\(>>1\) | Under-fitting |
\(<<1\) | Over-fitting |
The reason this works is because, here \(\chi^2\) is just sum of normally-distributed error terms
Probabilistic Evaluation¶
You can model the error such as MAE as a \(\chi^2\) distribution with dof = \(n-k\)
The uncertainty can be obtained from the distribution
Spurious Regression¶
Misleading statistical evidence of a relationship that does not truly exist
Occurs when we perform regression between
- 2 independent variables
and/or
- 2 non-stationary variables
(Refer econometrics)
You may get high \(R^2\) and \(t\) values, but \(u_t\) is not white noise (it is non-stationary)
Variance of error term becomes infinite as we go further in time
Classification Evaluation¶
Metric | Formula | Preferred Value | Unit | Range | Meaning |
---|---|---|---|---|---|
Entropy of each classification | \(H_i = -\sum \hat y \ln \hat y\) | \(\downarrow\) | \([0, \infty)\) | Uncertainty in a single classification | |
Mean Entropy | \(H_i = -\sum \hat y \ln \hat y\) | Uncertainty in classification of entire dataset | |||
Accuracy | \(1 - \text{Error}\) \(\dfrac{\text{TP + TN}}{\text{TP + FP + TN + FN}}\) | \(\uparrow\) | % | \([0, 100]\) | \(\dfrac{\text{Correct Predictions}}{\text{No of predictions}}\) |
Error | \(\dfrac{\text{FP + FN}}{\text{TP + FP + TN + FN}}\) | \([0, 1]\) | \(\downarrow\) | \(\dfrac{\text{Wrong Predictions}}{\text{No of predictions}}\) | |
F Score F1 Score F-Measure | \(2 \times \dfrac{P \times R}{P + R}\) | \(\uparrow\) | Unitless | \([0, 1]\) | Harmonic mean between precision and recall Close to lower value |
ROC-AUC Receiver-Operator Characteristics-Area Under Curve | Sensitivity vs (1-Specificity) = (1-FNR) vs FPR | Larger AUC Curve hugs the top left corner High sensitivity, high specificity | Unitless | \([0, 1]\) | How does the classifier compare to a classifier that predicts randomly How well model can discriminate between \(y=0\) and \(y=1\) |
Recall Sensitivity True Positive Rate | \(\dfrac{\textcolor{hotpink}{\text{TP}}}{\textcolor{hotpink}{\text{TP}} + \text{FN}}\) | \(\uparrow\) | Unitless | \([0, 1]\) | How many actual +ve values were correctly predicted as +ve |
Precision PPV/ Positive Predictive Value | \(\dfrac{\textcolor{hotpink}{\text{TP}}}{\textcolor{hotpink}{\text{TP}} + \text{FP}}\) | \(\uparrow\) | Unitless | \([0, 1]\) | Out of actual +ve values, how many were correctly predicted as +ve |
Specificity True Negative Rate | \(\dfrac{\textcolor{hotpink}{\text{TN}}}{\textcolor{hotpink}{\text{TN}} + \text{FP}}\) | \(\uparrow\) | Unitless | \([0, 1]\) | Out of actual -ve values, how many were correctly predicted as -ve |
NPV Negative Predictive Value | \(\dfrac{\textcolor{hotpink}{\text{TN}}}{\textcolor{hotpink}{\text{TN}} + \text{FN}}\) | Unitless | \([0, 1]\) | Out of actual -ve values, how many were correctly predicted as -ve | |
\(F_\beta\) Score | \(\dfrac{(1 + \beta^2)}{{\beta^2}} \times \dfrac{P \times R}{P + R}\) | \(\uparrow\) | Unitless | [0, 1] | Balance between importance of precision/recall |
FP Rate | \(\begin{aligned}\alpha &= \dfrac{\textcolor{hotpink}{\text{FP}}}{\textcolor{hotpink}{\text{FP}} + \text{TN}} \\ &= 1 - \text{Specificity} \end{aligned}\) | \(\downarrow\) | Unitless | \([0, 1]\) | Out of the actual -ve, how many were misclassified as Positive |
FN Rate | \(\begin{aligned}\beta &= \dfrac{\textcolor{hotpink}{\text{FN}}}{\textcolor{hotpink}{\text{FN}} + \text{TP}} \\ &= 1 - \text{Sensitivity} \end{aligned}\) | \(\downarrow\) | Unitless | \([0, 1]\) | Out of the actual +ve, how many were misclassified as Negative |
Balance Accuracy | \(\frac{\text{Sensitivity + Specificity}}2{}\) | Unitless | |||
MCC Mathews Correlation Coefficient | \(\dfrac{\text{TP} \cdot \text{TN} - \text{FP}\cdot \text{FN} }{\sqrt{(\text{TP}+\text{FP})(\text{TP}+\text{FN})(\text{TN}+\text{FP})(\text{TN}+\text{FN})}}\) | \(\uparrow\) | Unitless | \([-1, 1]\) | 1 = perfect classification 0 = random classification -1 = perfect misclassification |
Markdedness | PPV + NPV - 1 | ||||
Brier Score Scaled | |||||
Nagelkerke’s \(R^2\) | |||||
Hosmer-Lemeshow Test | Calibration: agreement b/w obs and predicted |
Graphs¶
Graph | Preferred | |
---|---|---|
ROC Curve | As high as possible At least higher than 45deg line | |
Calibration Graph | Along 45deg line |
Probabilistic Evaluation¶
You can model accuracy as a binomial distribution with
- \(n=\) Validation set size
- = No of predictions
- = No of k folds * Validation Set Size
- \(p=\) Obtained Accuracy of classifier
The uncertainty can be obtained from the distribution
for n in [100, 1_000, 10_000, 100_000]:
dist = stats.binom(n, 0.7)
alpha = 0.025
interval_width = dist.isf(alpha) - dist.isf(1-0.975)
print(f"Size: {interval_width/n * 100}")
# returns alpha % of observed accuracy that fall outside the inverval --> This is the maximum further accuracy that is theoretically achievable
Confusion Matrix¶
\(n \times n\) matrix, where \(n\) is the number of classes
Binary Classification¶
Multi-Class Classification¶
Confusion Matrix with respect to A
A | B | C | |
---|---|---|---|
A | TP | FN | FN |
B | FP | TN | TN |
C | FP | TN | TN |
Classifcation Accuracy Measures¶
Jacquard Index¶
F1 Score¶
Micro-Average | All samples equally contribute to average |
Macro-Average | All classes equally contribute to average |
Weighted-Average | Each class’ contribution to average is weighted by its size |
Macro Average¶
Weighted Average¶
Summary Statistics¶
Don’t just look at the mean evaluation metric of the multiple splits
Also use standard deviation & standard error to also get the uncertainty associated with the validation process.
Residual Analysis¶
Numerical | Graphical Plots | ||
---|---|---|---|
Random residuals | Normality test | Q-Q Plot of \(u_i\) Histogram for \(u_i\) | |
No explained systematic component | - No relationship between error and independent variables - If there is correlation, \(\exists\) unexplained system component | \(\text{Cov}(u_i, x_i) = 0; \text{Cov}(u_i^2, x_i) = 0\) : No covariance/correlation between \(u_i\) and \(x_i\) , and \(u_i^2\) and \(x_i\) | Line graph: \(u_i\) vs \(x_i\) Line graph: \(u_i^2\) vs \(x_i\) Line graph: \(u_i\) vs \(y_i\) Line graph: \(u_i^2\) vs \(y_i\) |
Goodness of fit | - MLE Percentiles - Kolmogorov Smirnov |
Perform all the plots for train and validation data
Numeric¶
-
Series of \(u_i\) are random
-
\(E(u_i | x_i) = 0\)
- Symmetric distribution for values of error terms for a given value \(x\)
- Not over time/different values of \(x\)
- This means that
- you have used up all the possible factors
- \(u_i\) only contains the non-systematic component
-
Homoscedascity of variance
- \(\text{var}(u_i | x_i) = \sigma^2 (u_i|x_i) = \text{constant}\) should be same \(\forall i\)
- For the Variance of distribution of potential outcomes, the range of distribution stays same over time
- \(\sigma^2 (x) = \sigma^2(x-\bar x)\)
else, the variable is volatile; hard to predict; we cannot use OLS
- if variance decreases, value of \(y\) is more reliable as training data
- if variance increases, value of \(y\) is less reliable as training data
- We use volatility modelling (calculating variance) to predict the pattern in variance
Why is this important?¶
For eg: Running OLS on Anscombe’s quartet gives
- same curve fit for all
- Same \(R^2\) for all
But clearly it is not optimal
which is shown in the residual plot
Log Likelihood¶
def ll(X, y, pred):
# return log likelihood
mse = np.mean(
(y - pred)
**2
)
n = float(X.shape[0])
n_2 = n/2
return -n_2*np.log(2*np.pi) - n_2*np.log(mse) - n_2
def aic(X, y, pred):
p = X.shape[1]
return -2*ll(X, y, pred) + 2*p
print(aic(X, y, pred))
Evaluation Curves¶
Related to Interpretation
Always look at all curves with uncertainties wrt each epoch, train, hyper-parameter value. The uncertainty of the train set and test set should also be similar. If train set metric uncertainty is small and test set metric uncertainty is large, this is bad even if the average loss metric is same
Learning | Loss | Validation | |
---|---|---|---|
Loss vs | Train Size | Epochs | Hyper-parameter value |
Comment | Train Error increases with train size, because model overfits small train datasets | ||
Purpose: Detect | Bias Variance Utility of adding more data | Optimization problems Undertraining Overtraining | Model Complexity Optimal Hyperparameters |
No retraining | ❌ | ✅ | ❌ |
No extra computation | ❌ | ✅ | ❌ |
Learning Curve¶
Conclusion | Adding more data will help | Comment | |
---|---|---|---|
High Bias (Underfitting) | ❌ | Model can’t fit larger datasets | |
High Variance (Overfitting) | âś… | ||
High Bias High Variance |
Loss Curve¶
Same Model, Variable Learning Rate¶
IDK¶
Phase | Hessian | Mode Connectivity | Model Similarity | Treatment |
---|---|---|---|---|
1 | Large | -ve | Low | Larger network |
2 | Large | +ve | Low | Smaller learning rate |
3 | Small | -ve | Low | Larger network |
4-A | Small | \(\approx 0\) | Low | Increase train size |
4-B | Small | \(\approx 0\) | High | âś… |
